Build a machine-specific lockout tagout procedure template
Start with the empty document above. Click the machine name, location, photo areas, or step cells to fill them in. Add a step for each hazardous energy source, including its magnitude, isolation point, device, lockout action, and verification method. Your printable procedure updates as you type, with no account required.
Use the equipment photo and source photos to help workers identify the correct machine and isolation points. Check the details against the actual equipment and your energy control program before printing.
A lockout/tagout procedure template is a fill-in structure for one machine’s energy control procedure: equipment details, each energy source with its isolation point and device, shutdown and isolation steps, stored-energy controls, and verification. The template below follows OSHA 1910.147(c)(4); complete one per machine, not per machine family.
What OSHA requires the procedure to contain
Section 1910.147(c)(4) lists exactly what a machine-specific procedure must document. A compliant template needs fields for all of it:
- Intended use: the scope, purpose, and the machines or equipment covered
- The specific procedural steps for shutting down, isolating, and securing the equipment
- Steps for the placement, removal, and transfer of lockout/tagout devices and who has responsibility for them
- Requirements for testing the machine to verify the effectiveness of the lockout
- Machine-specific identification: equipment ID, location, and every energy source with its type and magnitude
The template: header block
Start every procedure with an identification block. It sounds bureaucratic until the day an inspector asks "which machine is this for?" and the procedure cannot answer.
- Procedure title and unique ID (e.g., LOTO-M11-001)
- Equipment name, model, and asset/location ID (e.g., Mixer M-11, Building 3, Line 2)
- Energy sources summary (use values verified on the actual equipment; do not copy example values)
- Required PPE (e.g., arc-rated face shield for panel work)
- Written by / reviewed by / approval date
- Revision number and revision date
The template: energy source table
One row per energy source. The discipline of the table is what keeps a tech from missing the second, third, or fourth energy source, the classic cause of LOTO incidents.
- Energy type (electrical, hydraulic, pneumatic, mechanical, thermal, chemical, gravitational)
- Magnitude and units, verified for the actual equipment and operating configuration
- Isolation point, identified by the exact site-verified equipment label or identifier
- Lockout device required (breaker lock, valve lockout, blank flange, chain + lock)
- Stored/residual energy and the employer-approved control and verification method for that equipment
| Energy source | Magnitude | Isolation point | Lockout device | Stored energy |
|---|
| [verified source] | [verified magnitude and units] | [verified isolation identifier] | [selected device] | [site-approved stored-energy control and verification] |
The template: the seven sequence sections
Use the employer’s equipment-specific sequence. Section 1910.147(d) lists the required application actions; affected-employee notification is separately addressed in 1910.147(c)(9). This checklist is a framework, not a procedure to use on equipment:
- Prepare: the authorized employee knows the type and magnitude of energy, its hazards, and the means of control.
- Shut down: use the equipment-specific shutdown procedure and avoid creating additional hazards.
- Isolate: locate and operate all energy-isolating devices needed to isolate the equipment.
- Apply devices: authorized employees apply the required lockout or tagout devices.
- Control stored energy: relieve, disconnect, restrain, or otherwise render hazardous stored or residual energy safe; continue verification if it can reaccumulate.
- Verify: before work, an authorized employee verifies isolation and deenergization using the method specified by the employer’s procedure and applicable safety rules.
- Return to service: follow 1910.147(e), including checking the work area and employees, device removal, and affected-employee notification.
How to fill the template out in the field
Have the employer’s qualified reviewers compare the draft with equipment documents and a safe site walkdown with employees who service it. Record verified identifiers and conditions. Do not approach equipment, remove guards, operate isolation devices, or take photos unless the employer’s safe work process permits it.
Document relevant secondary sources, stored or residual energy, and access constraints in the procedure after the employer verifies them. The procedure must reflect the actual equipment; this article’s examples are not instructions to use on a machine.
Template mistakes that become citations
Before rollout, have qualified site reviewers check the draft for these common gaps:
- Generic procedures ("isolate all energy") with no named isolation points
- Missing or unverified energy magnitudes and units
- No verification step, or a verification step that only checks one energy source
- No stored-energy section for equipment with springs, accumulators, or suspended parts
- Vague restart responsibility: OSHA requires the procedure to state who removes locks and when
- One procedure covering "all mixers" when mixers differ by model, vintage, or feed configuration
From paper template to living document
A template solves consistency, not currency. The moment after rollout, equipment changes, panel labels wear off, and the printed copies on machines drift from the master file. That is why mature programs move the template into a system where each machine has a current record, isolation photos, and a QR code at the asset that opens the live version.
However you host it, keep two rules: every machine has exactly one current procedure, and the version at the machine is the version in the system. The template above is the skeleton: the discipline around it is the program.
This template organizes equipment details; it is not an OSHA-approved form or a guarantee of compliance. Review it alongside your equipment manuals, 29 CFR 1910.147, and your site’s complete energy control program.
Choose an export format
Word (.docx) gives you a formatted procedure with instructions, photos, and a step table. Excel (.xlsx) organizes the same details in a workbook set up for landscape printing. Print / Save PDF preserves the layout shown on this page. Word and Excel include editing protection that some apps can remove or ignore.
Keep your procedures together in Tegis
When you need shared access, QR links, revision control, and a saved procedure library, create a free account.
Request a demo →Frequently asked questions
Does the template upload my procedure?
No. Procedure text and photos stay in your browser while you edit and print the template.
Can I download a lockout tagout procedure template in Word or Excel?
Yes. Fill in the online template, select Export procedure, then choose Word (.docx), Excel (.xlsx), or Print / Save PDF. Word and Excel downloads include formatted instructions and embedded photos, with editing protection to prevent accidental changes. This protection can be removed or ignored by some apps. PDF preserves the online document’s page layout.
Can I save the procedure for later?
Print or save a PDF before leaving this page; the editable draft is not saved when you close or refresh it. A Tegis account lets you save, edit, share, and manage procedures over time.
How many lockout steps can I add?
Add as many hazardous energy steps as the equipment requires. Extra steps continue onto additional printable pages.
Is a generic lockout/tagout template enough for compliance?
No. OSHA requires machine-specific procedures for machines with multiple energy sources or where a single isolation does not fully de-energize the equipment. A template is the format; each machine needs its own completed procedure with named isolation points and magnitudes.
Does OSHA approve or certify LOTO procedure templates?
No: OSHA does not approve templates or programs. Compliance is determined by whether your actual procedures meet 1910.147(c)(4) and whether they are followed in the field. Templates labeled "OSHA-approved" are marketing, nothing more.
Can one procedure cover several identical machines?
Yes, in limited cases: 1910.147 allows a single procedure for a group of machines with the same type and magnitude of energy, the same isolation methods, and the same type of lockout devices. The procedure must clearly identify which machines it covers, and if any machine deviates, it needs its own.
How often should templates be reviewed?
OSHA requires periodic inspection of each applicable energy-control procedure at least annually. The inspector must be an authorized employee other than the employee(s) utilizing that procedure during the inspection. Correct identified deviations or inadequacies and provide retraining when required.
Can consultants reuse this template for client work?
Yes. The template is free to use and adapt for the procedures you deliver to clients. If you deliver many client procedures, procedure software turns this format into reusable, QR-ready client deliverables.
